KS2838

KS4824

216BR14

KSK2835

Orange Bag of KSK Compound

Better grip and long life

Laser marker parts number inside

KS4820

64 Pitch only for PN 64 Pitch Spur Gear use

164435

NEW V4 Version

Motor Can

- the all new motor can has bigger and more ventilation holes allowing better heat dispersion thus providing better run time

- front section has evenly spaced mounting screws holes that is compatible and fits for all after market motor holder and chassis

End Cap

- newly designed end cap now comes with side locking screws that firmly secures the end cap and PCB.

Stator

- high temp wires used for longevity

- proprietary wiring producing better speed, torque and smoothness

Changeable armature

New design air vent gets more cooling

High-Temperature wire

15mm diameter motor can, same as normal brushed 130 motors. Fits in all Kyosho, PN, and aftermarket motor mounts.

Fits in all Mini-Z chassis AWD, F1, MR02, MR03, MR04

Much more torque and acceleration than other VE motors.

No loading RPM 22000 on 4.8V, amp draw only 0.28A

Four mounting holes to allow different angles of motor terminals.

Eight venting holes prevent heat buildup.

Can and end bell ball bearing from Japan.

Recommend gear ratio 3.95 to 5.00

Connection M1 to Orange Wire, M2 to Yellow Wire, M3 to Blue Wire

Recommend wire #700122

Replacement endbell screws #183002

700385

These batteries have a high voltage level under load, with low internal resistance.

Designed for use with 1/28 scale car

Atomic - BZ AMZ FFZ MRZ SZ

GL Racing - GLA GLR GLRGT GLF GLD

RTRC Chassis

Specification

Voltage: 7.4V (2S)

Capacity: 385mAh

Recommend Charge Rate: 0.8A

C-rate: 70C

Cable: 24Awg

Plug: JST-PH

Type: Rectangular

Size: 44.8 x 20 x 11.9mm (Length x Width x Height)

Weight: 19.5g

MR2046A

288YR0

600500O

PNWC 2024 Paris allowed body for 2WD Stock and GTLM Super Stock class

Description

Configurable for 98mm wheelbase.

The body comes unpainted. painting is not necessary as it was made of white color material with a glossy finish

Features Reversible Side Body Clip which allows lowering body height by 1mm when installed in the reversed order.

Includes

Lexan Roof

Lexan Spoiler

Front & Side Body Clips

Headlight Taillight Lens in Clear

Headlight Taillight Lens in Red

Screws

Requirement

Kyosho Mini-Z MR-02, MR-03, PN 2.5W

GL Racing GLA, GLR

Atomic AMZ, BZ

KS1142

Brand New Low Profile Tires

PN Racing KS & KS-M compounds are our most popular race proven tire compounds

PN Racing KS Compound: its known to offer more grip as the tire heat up and long duration.

PN Racing KS-M Compound: its known to offer quick warm up and good grip from beginning of the race, also suitable for tracks in cold climate.

After months of R&D, we can finally release our brand new low profile high performance tires.

Our new low profile tires are 1.6mm thick, when its installed on the 20mm rims, the diameter will be 23.2mm.

For stock class you don't have to true these tires, it will be broken in after running on RCP track for one battery pack.

For more advanced classes, only the surface (0.1-0.2mm) needs to be trued.

8.5mm tires

KS Compound

KS1130 Slick Front Tire (8.5mm) SUPER SOFT

KS1134 Slick Front Tire (8.5mm) SOFT

KS1138 Slick Front Tire (8.5mm) MEDIUM

KS1142 Slick Front Tire (8.5mm) Hard

KS-M Compound

KSM530 Slick Front Tire (8.5mm) SUPER SOFT

KSM534 Slick Front Tire (8.5mm) SOFT

KSM538 Slick Front Tire (8.5mm) MEDIUM

KSM542 Slick Front Tire (8.5mm) Hard

11mm tires

(If you use 14mm rear tire, this is perfect front tire to use with 11mm wheels)

KS Compound

KS2130 Slick Tire (11mm) SUPER SOFT

KS2134 Slick Tire (11mm) SOFT

KS2138 Slick Tire (11mm) MEDIUM

KS2142 Slick Tire (11mm) Hard

KS-M Compound

KSM630 Slick Tire (11mm) SUPER SOFT

KSM634 Slick Tire (11mm) SOFT

KSM638 Slick Tire (11mm) MEDIUM

KSM642 Slick Tire (11mm) Hard

700505A

• PN Lexan Body Kit 600800K for Mini-Z MR03 and PN 2.5 Chassis

• Configurable for 98mm wheelbase.
• The body comes unpainted.
• 0.7mm Version


• Kyosho Mini-Z MR-02, MR-03 or PN 2.5W chassis
• 1/28 2WD, AWD Chassis e.g. GL Atomic


216BR0

• Configurable for 98mm wheelbase.
• The body comes unpainted.
• 0.7mm Version


• Kyosho Mini-Z MR-02, MR-03 or PN 2.5W chassis
• 1/28 AWD Chassis e.g. GL Atomic

• PN Lexan Body Kit 600800K for Mini-Z MR03 and PN 2.5 Chassis

64 Pitch only for PN 64 Pitch Spur Gear use

KSM220
